2026 Manitou Group MT 1440 ST5
Get in Touch
Description
2026 Manitou Group MT 1440 ST5
The MT 1440 telehandler has been specifically designed for jobsites requiring significant lifting heights. With a 4-ton lifting capacity, it allows you to safely place pallets up to 14 meters high.Robust and reliable, it features a reinforced low steel door and an electric window, reducing the risk of damage in the most demanding environments. The cab offers optimal visibility, allowing you to keep a constant eye on your load and surroundings right up to the drop-off point.Easy to transport from one site to another thanks to its numerous lifting points, the MT 1440 is also built for all terrains, with a 42 cm ground clearance, three steering modes, and four-wheel drive.
Info
Industry
Agriculture
Make
Manitou Group
Model
MT 1440 ST5
Trim
Base
Year
2026
MSRP
N/A
Category
Telehandler
Subcategory
General
Specs
Load Capacity
Max. capacity: 8818 lb
Length
Overall length to carriage: 19 ft 9 in | Length to face of forks: 20 ft 1 in | Forks: 47 in
Notes
Max. outreach: 31 ft | Breakout force with bucket: 7895 daN | Tilt-up angle: 12 ° | Tilt-down angle: 114 ° | Lifting: 16 s | Lowering: 12.40 s | Extension: 17.30 s | Retraction: 13 s | Crowd: 4.30 s | Dump: 4 s | Drawbar pull (Laden): 9930 daN | Number of gears (forward / reverse): 4 / 4 | Max. travel speed: 15 mph | Hydraulic pump type: Gear pump | Hydraulic flow / Pressure: 44 US gpm-3916 PSI | Noise at driving position (LpA): 79 dB | Noise to environment (LwA): 106 dB | Vibration on hands/arms: < 8 ft/s² | Cab certification: Cabin ROPS - FOPS level 2 | Controls: JSM
Height
8 ft | Max. lifting height: 44 ft 5 in
Width
7 ft 9 in | Overall cab width: 2 ft 11 in | Forks: 5 in
Wheelbase
10 ft 1 in
Ground Clearance
1 ft 3 in
Turning Radius
External turning radius (over tyres): 12 ft 11 in
Weight
24119 lb | Unladen weight (with forks): 24119 lb
Tires
Inflatable | Alliance 400/80 - 24 - 162A8
Engine
Deutz | Stage V
Cylinders
Number of cylinders / Capacity of cylinders: 4 - 221 in³
Power/Horsepower
100 Hp / 75 kW
Torque
302 ft/lbs @ 1600 rpm
Transmission
Torque converter
Brakes
Parking brake: Automatic parking brake | Service brake: Oil-immersed multi-discs braking on front & rear axles
Oil Capacity
3 US gal | Hydraulic oil: 36 US gal
Fuel Capacity
37 US gal | Diesel Exhaust fluid (AdBlue® type) tank capacity: 6 US gal
Steering
Steering wheels (front / rear): 2 / 2
Wheels
Drive wheels (front / rear): 2 / 2
