2026 Manitou Group MHT 11250 ST5
Get in Touch
Description
2026 Manitou Group MHT 11250 ST5
The MHT 11250 is a telescopic handler with a capacity of 25 tonnes and a maximum lifting height of 11 metres. Equipped with a 211 hp engine and hydrostatic transmission, the MHT 11250 telescopic handler can handle heavy and bulky loads in complete safety and on any type of terrain thanks to its 4-wheel drive and steering. A wide range of attachments can be installed: forks, positioner, hook and winch, bucket, basket and tyre clamps, cylinder clamps and pipes clamps. For maximum comfort, this machine is equipped with an ergonomic panoramic cab, Easy Step access, JSM joystick and colour touch screen.
Info
Industry
Agriculture
Make
Manitou Group
Model
MHT 11250 ST5
Trim
Base
Year
2026
MSRP
N/A
Category
Telehandler
Subcategory
General
Specs
Load Capacity
55113 lb
Notes
Load center of gravity: 35 in | Max. outreach: 19 ft 8 in | Tilt-up angle: 10 ° | Tilt-down angle: 106 ° | Frame leveling corrector: 10 ° | Engine cooling system: Water | Drawbar pull: 20400 daN | Number of gears (forward / reverse): 2 / 2 | Max. travel speed: 16 mph | Gradeability (laden / unladen): 31.50 % / 57.70 % | Hydraulic pump: type Variable displacement pump | Hydraulic flow - Pressure: 76 US gpm - 5076 PSI | Noise to environment (LwA): 109 dB | Vibration on hands/arms: < 8 ft/s² | Noise at driving position (LpA) tested following NF EN 12053 norm: 75 dB | Cab certification: Cabin ROPS - FOPS level 2 | Controls: JSM
Height
Max. lifting height: 34 ft 9 in | 10 ft 1 in
Length
29 ft 3 in | Length to face of forks: 23 ft 4 in | Forks: 71 in
Weight
Unladen weight (with forks): 72642 lb
Ground Clearance
1 ft 7 in
Wheelbase
13 ft 5 in
Width
9 ft 2 in | Overall cab width: 3 ft 1 in | Forks: 9 in
Turning Radius
External turning radius (over tyres): 18 ft 1 in
Tires
18.00 R25
Wheels
Number of front wheels / rear wheels: 2 / 2 | Drive wheels (front / rear): 2 / 2
Steering
2 wheel steer, 4 wheel steer, Crab mode
Engine
Yanmar | Stage V, Tier 4
Cylinders
Number of cylinders / Capacity of cylinders: 4 - 279 in³
Power/Horsepower
211 Hp / 155 kW
Torque
594 ft/lbs@1500 rpm
Battery
2 | Battery voltage: 12 V
Transmission
Hydrostatic
Brakes
Parking brake: Automatic negative parking brake | Service brake: Oil-immersed multi-discs braking on front & rear axles
Oil Capacity
3 US gal | Hydraulic: 77 US gal
Fuel Capacity
83 US gal | Diesel Exhaust fluid (AdBlue® type) tank capacity 6 US gal
